FEATURES
Standard dimension
Thickness tolerance
Flatness tolerance
Standard grid
Standard slit width
Operating conditions
Protective coating
6000 x 2500 mm
EN10029 Class B
EN10029 Class N steel type H
19 slits in length, 7 slits in width of plate
2.4 mm over full depth of Top wear Layer
-46 °C min, 200 °C max
UV shop primer 75 µ optional
IN STOCK 6000 x 2500 mm plate
Thickness (mm)
12
14
18
20
25
30
Weight (kg)
1412
1647
2118
2354
2942
3530
50%-50%
6h+6 mm
7h+7 mm
9h+9 mm
10h+10 mm
12,5h+12,5 mm
15h+15 mm
60%-40%
7h+5 mm
​
​
12h+8 mm
15h+10 mm
67%-33%
​
9h+5 mm
12h+6 mm
13h+7 mm
REDUCES DOWNTIME
Our Fedur plates for your focus on uptime and durable products.
Using Fedur reduces the need for replacing parts, means less maintenance and reduces costs.
Fedur plates are designed to withstand the challenges of any harsh climate, terrain or environment.
Practical examples of Fedur slurry transports illustrate that the life of Fedur fitting can be up to 10 times longer than conventional fitted parts. By focusing on a combination of material and flow properties, we are able to create a durable solution.
This reduces the need for replacing parts, means less maintenance, less downtown and significantly reduces life cycle cost.
